220V Surgical Glove Paper Wallet Type Wrapping Machine With Special Customized Hand Mold For Wrist Flipping

220V Surgical Glove Paper Wallet Type Wrapping Machine With Special Customized Hand Mold For Wrist Flipping

Brand Name:	Sayok
Model Number:	SN-100TK
MOQ:	1 set
Price:	EXW US$50770 -55080/set
Payment Terms:	T/T
Supply Ability:	10 set/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

Glove Size:

250mm

Feature:

Multi-language Support

Keyword:

Surgical Glove Packing Machine

Automatic Grade:

Automatic Wallet Packing

Machine Appearance:

Stainless Steel

After Sales Service:

Technical Video Support

Production Capacity:

50bag/min

Spare Parts:

1 Set Free With Machines

Packaging Details:

Exported wooden case

Product Description

220V Surgical Glove Paper Wallet Type Wrapping Machine With Special Customized Hand Mold For Wrist Flipping

This automatic surgical glove wallet‑style packaging machine is a specialized integrated packaging solution designed for medical surgical glove inner wrapping, fully compliant with medical GMP production standards and sterile packaging requirements. It combines with host folding part, glove transfer mechanism and collection bin 3 parts, all of these 3 parts are customized and compact design for surgical wallet wrapping.

Different from fully automatic glove packaging equipment, this machine adopts manual glove loading on customized wrist flipping mechanism as the front‑end feeding process, which ensures accurate glove positioning and effectively avoids deformation and dislocation of thin surgical gloves during packaging. After manual sleeving, all subsequent core processes are completed automatically, including automatic wrist flipping, paper roll unwinding and precision cutting, then moving for wrapping, glove grisping, clamping and positioning and standard wallet style folding. The one‑step integrated workflow greatly simplifies production procedures and improves packaging consistency.

Equipped with high‑precision servo control system and stable mechanical transmission structure, the machine features stable operation, accurate folding sizing and low failure rate. It adopts medical‑grade packaging paper compatible with sterile surgical gloves, realizing neat, flat and standardized wallet‑type inner packaging, which lays a solid foundation for subsequent four‑side sealing and outer pouch packaging. All are controlled with high sensitive sensors to make sure the precision positioning and packing, and alerting for the defaults.

Featuring compact structure, easy operation and convenient maintenance, the equipment supports packaging of all common sizes of surgical gloves. It is widely applicable to formal production lines of medical glove manufacturers, meeting the high standard and high‑efficiency production demands of medical disposable protective supplies.

Process

The inner lining paper film is put on the shelf→paper feeding film--precise cutting film--paper-absorbing film to the packaging area--manipulator picking up gloves--glove positioning and placement--paper mold folding--packing completion--Output

Main Technical Parameter

Model	SN-100TK
Product	Surgical Gloves
Packing Film Range	256 x 380 - 460mm
glove size	size 6.5-8.5 (L180-220mm, W95-140mm)
pack qty/time	1 pair/time
packing speed	24-28 bag/min
Paper film request	38-40g single shiny paper with good flexible, stiffness
Power	220V 50/60 HZ 5KW
Machine Size	(LxHxL)3100x3000x1800mm
Machine weight	1200 KG
Compressed Air	O.6-0.8 Mpa approx 30 NM/H, 7.5KW air compressor will be ok

Machine Details

1. Stailess steel appearance for good looking and durable in use. It is a high-tech product integrating light, electricity, air and machine. Suitable for surgical gloves lined with paper packaging
2. High quality glove flip wrist transfer mechanism, workers is easy to flip wrist, and there are different glove meter in the mold, very convenient to change mold size to fit different glove size.
3. Large film roll holder, stretching in a timely manner and reduce the film roll changing time.
4. Automatic paper cutting and moving to positioned place for glove folding.
5. The manipulator is positioned so that the product will not be crushed during sealing. Automatic grasp the left and right hand gloves from the mold. Less manual contact for greater cleanliness and hygiene.
6. Automatic swing folding, wallet type packing, convenient for the doctor's to opening and wear. With medical paper lining packing, which is okay to pass the sterilization.
