PLC Controlled Stretch Film Wrapping Machine IV Tube Four Side Sealing Machine
Feature:
1. It requests for the fims with good stretchability.
2. Adopts advanced cutters.
3. Equipped with edge waste recycling system, make sure the enviroment is clean
4. Eqipped with cooling system to the mould.
5. Stainless steel appearance, clean and durable
6. PLC touch screen to ease the data setting.
Quick Details:
1. Automatic computerized knife adjustment;
2. Adopt imported high quality vacuum, durable and reliable.
3. Easy to operate, convenient in use.
4. One machine, multiple uses, only change related mould.
5. Color cover film or light film can be used for packaging to reduce costs and improve product quality
6. Can be equipped with automatic coding or coding system according to the client's packaging requirements.
Specifications:
|
|
Machine Details:
| 1. Film Stretching The lower film is first mounted on the reel and driven to the forming area by the running of the chain. |
 |
| 2. Stretching and Forming When the lower film runs below the forming plate, the lower film is heated by the heating plate and then the film is stretch to form the shape of the mold to prepare for next material filling. |
|
| 3. Material Filling Workers place the products into the lower film cavity of the stretch molding manually and then run by the chain to the next link. |
|
| 4.Upper Film Covering The upper film will cover the lower film cavity after placing the material, thus forming a form of packaging by wrapping the product with the upper and lower films. |
|
| 5. Vacuum sealing Heat sealing and vacuuming of the product |
|
| 6. Printing date Pring date as client's requirements |
|
| 7. Product Segmentation The cutter will cut the product horizontally and then longitudinally,then the finished product is complete |
|
