Customization 5 Lines Four Side Seal Packaging Machine For Mosquito Coil Mat With Automatic Feeder
Sayok's Model SN-280A is a multi lines four side seal packing machine, it is compact designed for Car Fragrance Tablet, Drying Tablet, Mosquito Fragrance Tablet, Hotel Soap, Drying Tablet, Aromatherapy Tablet and Compressed Biscuits Cookies etc flat square blocks' packaging.
This four side seal packing machine adopts color touch screen operation, which is very easy to do the setting adjustment, easier for workers to operate and setting. And it is an intelligent packing machine controled by servo motors, the machine is more stable in use.
And the feeding device is customized according to actual products, clients can customize the feeding lines according to actual requirements. The film roll holder is large & strong enough to hold the film, though it is 6 lines, it can be handle firmly.
Separate PID temperature system, easy to control the temperature, clients can be freely to choose plastic film, AL film or other laminated film.
More, clients can optional to add liquid filling system, adopts high quality pump, dose the liquid filling, which is very friendly for car fragrance tablet, mosquito pad etc products need liquid filling. Once you produce the product no need the liquid filling, just close it from screen.
-
Specifications:
| Model |
SN-280A
|
| Bag Size |
(L) 50mm×(W)50mm, to be customized |
| Film requirements |
73-110g/ ,paper-aluminum film composite wrapping paper, Φ≤350 mm, width 400 mm, inner diameter of paper core 76.2
|
| Inner diameter of raw paper core |
Φ 76.2mm (=3") |
| Power |
220v ,50hz ,5.5 kw |
| Packing Speed |
200-280 Bag/min, depends on products |
| Machine Size |
(L*W*H)3300×1300×1600mm |
| Weight |
500 KG |
| Applications |
suitable for Car Fragrance Tablet, Drying Tablet, Mosquito Fragrance Tablet, Hotel Soap, Drying Tablet, Aromatherapy Tablet and Compressed Biscuits Cookies etc square blocks' packaging |
| Optional items |
packing lanes can be customized. |
Machine Details:
|
1. Packaging machine appearance
High quality stainless steel appearance, durable and long life in use.
|
 |
|
2.Automatic feeding design
It can realize the one-step process of material release, packaging and sealing and cutting, 4 lanes design for high productivity. Big film roll holder, can support different size product and films.
|
|
|
3. Automatic bag forming
Good quality hardness cutter to devide, make sure each bags with neat edges. Automatic bag forming from fill rolls, save time and cost.
|
|
|
4.Good sealing and no leaking issue
Four side seal packing with good sealing effect, meet medical supplies and other products requires for high sealing. And equipped with easy tearing stripe, it is very convenient for comsumer to open the package.
|
|
|
5. Control System
High quality big brand servo driven system, make sure the machine can be operating stablely.
|
|
|
6. Applications
Multiple sizes available, widely use for different product size, suitable for Car Fragrance Tablet, Drying Tablet, Mosquito Fragrance Tablet, Hotel Soap, Drying Tablet, Aromatherapy Tablet and Compressed Biscuits Cookies etc square blocks' packaging.
|
|
Support and Services:
This counting packing machine product comes with comprehensive Product Technical Support and Services to ensure optimal performance and efficiency. Our technical support team is available to assist with troubleshooting, maintenance, and any technical inquiries you may have regarding the machine.
If your workers do not know how to operate the machine, can also contact our sales to book for technicians on-line instructions. The main electrical parts will be with 1 year warranty, excluding damages caused by human factors.
Packing and Shipping:
Description: Our Counting Packing Machine is designed to efficiently package straight stick products in a hygienic and convenient manner. It is suitable for use in various settings, including restaurants, hotels, and home kitchens.
Features:
- Automated operation for increased efficiency
- Compact design for space-saving
- Adjustable settings for different packaging requirements
- Durable construction for long-lasting use
Product Packaging:
The Filling Packing Machine will be securely packed in a sturdy cardboard box to ensure safe transport and delivery.
Shipping:
Step 1: Cleaning the machine in a timely manner;
Step 2: Secure the machine to the wooden crate, fixing 4 corners of the machine with the small wooden blocks to prevent from sliding during dispatching;
Step 3: Stretch film wrapping the machine and use cardboards to protect 4 sides from crushing.
Step 4: Nailing to firmer the exported wooden crates to avoiding falling apart during trasmit.
Step 5. Cooperate with professional forwarder and logistics with good reputations for shipping, can cooperate well with nominated forwarder if in need.
