Name: ODM Automatic Strip Packaging Machine Flat Effervescent Tablet Packing Machine
Brand: Foshan Sayok Intelligent Machinery Co., Ltd.，
SKU: SN-280A
Price: 10,194.00 USD
Availability: InStock

ODM Automatic Strip Packaging Machine Flat Effervescent Tablet Packing Machine

1 set

MOQ

Negotiate

Price

Features Gallery Product Description Request A Quote

Features

Specifications

Attitude: Intact

Applicable Industries: Food, Beverage, Commodity, Medical

Packaging Material: Plastic Film

Key Selling Points: Automatic

Automatic Grade: Automatic

Driven Type: Mechanical

After-sales Service: Video Technical Support

OEM/ODM: YES

Highlight:

ODM Automatic Strip Packaging Machine

Flat Effervescent Strip Packaging Machine

Basic Infomation

Place of Origin: China

Brand Name: Sayok

Certification: CE

Model Number: SN-280A

Payment & Shipping Terms

Packaging Details: Exported wooden case

Delivery Time: 15-30 working days

Payment Terms: T/T, Western Union, Western Union, Western Union

Supply Ability: 50 set /month

Gallery

ODM Automatic Strip Packaging Machine Flat Effervescent Tablet Packing Machine

Product Description

Automatic Strip Packaging Machine Flat Effervescent Tablet Packing Machine

FEATURES AT A GLANCE
1. Color touch screen operation interface operation; Servo drive system is adopted; PLC programmable controller intelligently controls the operation of the whole machine, precise film feeding, stable transmission of cotton sheets, and precise bag cutting.
2. Inlet liquid pump, the amount of liquid added can be set directly on the touch screen.
3. Under the premise of high liquid volume, the sealing is tight, no liquid leakage, no foaming
4. Independent guide column die set, mobile synchronous heat sealing system, the temperature of the sealing surface is more uniform and stable, the edge sealing is tight, and it is durable! .
5. Packaging materials of different thicknesses and materials have wider adaptability.
6. Multi-purpose: This machine is also suitable for: single film automatic slitting and sealing.

Specifications:

Model	SN-280A
Bag Size	(L) 50mm×(W)50mm, to be customized
Film requirements	73-110g/ ,paper-aluminum film composite wrapping paper, Φ≤350 mm, width 400 mm, inner diameter of paper core 76.2
Inner diameter of raw paper core	Φ 76.2mm (=3")
Power	220v ,50hz ,5 kw
Packing Speed	200-280 Bag/min
Machine Size	(LWH)2800×1300×1500mm
Weight	500 KG

Machine Details:

1. Packaging machine appearance It can realize the one-step process of material release, packaging and sealing and cutting
2.stable transmission of cotton sheets, and precise bag cutting.
3. Automatic production bag The rolling film is placed, the edge of the fully automatic bag is sealed, and different coils are supported.
4.Automatic bag making Roll film on the machine, fully automatic bag-making edge sealing beautiful, support different rolls of material.
6. Multiple sizes available
