50Hz 13KW Automatic Bag Packaging Machine Sealing High Performance

1 set
MOQ
EXW US$33538-39692/set
Price
50Hz 13KW Automatic Bag Packaging Machine Sealing High Performance
Features Gallery Product Description Request A Quote
Features
Specifications
Brand: Sayok
Model: SN-350ZD
Packing Film: OPP, CPP, PP, PE
Machine Weight: Approx. 900kg
Highlight:

50Hz Automatic Bag Packaging Machine

,

13KW Automatic Bag Packaging Machine

,

13KW Auto Bag Packaging Machine 13KW

Basic Infomation
Place of Origin: China
Brand Name: Sayok
Certification: CE
Payment & Shipping Terms
Packaging Details: Exported wooden case
Delivery Time: 30-40 working days
Payment Terms: T/T
Supply Ability: 50 set/month
Product Description

High Performance Bagging Machine Auto Cosmetics Commodities Rice Bricks Back Sealing Packaging Machine

Features:



1. The machine works smoothly and continuously, and is suitable for bagging and sealing of various masks, medical supplies, hygiene products, food and other products.

2. Fully automatic bagging, photoelectric correction, no burrs, failure molding.

3. The equipment can be configured with different types of feeders.

4. Using Panasonic PLC imported from Japan, the accuracy is improved and the equipment stability is high.

5. Intermittent sealing is better to ensure the beauty of the sealing and avoid leakage.

6. The whole machine is covered with stainless steel, with good appearance, easy to clean and durable. Low operation and maintenance costs.

7. The machine is easy to operate, PLC touch screen, can adjust the package according to the packaging material, product thickness and length

Loading temperature and speed. servo motor. Through the control of light, electricity and gas, the fault can be self-diagnosed and displayed clearly.

8. The required number of automatic alarm reminders, the required number of automatic batching and stacking.

9. According to the product, the card machine can be distributed to form a fully automatic bagging and packaging line.



Model  SN-350ZD
Film outer meter  Max.450mm
Packing Film  OPP, CPP, PP, PE
Bag length Max 300 mm
Bag width 100-280mm
Product’s height 1-10mm (can be customized by product)
Packing speed  40-60bags/min (depends on product)
Power 380V 50/60HZ 13KW
Air Source  0.6MP<Pressure<08MP m
Machine dimension (L*W*H) 4000x4000x800mm
Machine weight Approx. 900kg
